DB9 Connector | 9 Pin D-Sub Connector

Use the filter below to find the DB9 connector series containing a 9 pin d-sub in either cable or board mount options designed in both IP rated and non-rated versions. NorComp designs and manufactures one of the most comprehensive DB9 connector product offerings available on the market today.

DB9 Connector Series

Series

Description

Crimp

Solder Cup

IDC

Vertical

Right Angle

Dual-Port

SMT

Press Fit

IP67

170 Series

db9 connector | crimp and poke d-sub connectors | 170 series
Standard Density Crimp & Poke D-Sub Connectors check

171 Series PCB Dip Solder

db25 connector | 171 series dip solder d-sub connector
Standard Straight D-Sub Connectors | Stamped Contacts check

171 Series Solder Cup

db15 connector | 171 series solder cup d-sub connector
Standard Solder Cup D-Sub Connectors | Stamped Contacts check

172 Series High Profile

172 series d-sub high rise connector | 25 pin d-sub
Standard High Profile D-Sub | Machined Contacts check

172 Series PCB Dip Solder

172 series d-sub vertical mount connector | 9 pin d-sub connector
Standard Straight D-Sub Connectors | Machined Contacts check

172 Series Solder Cup

db15 connector | 172 series solder cup d-sub connector
Standard Solder Cup D-Sub | Machined Contacts check

172 Series Wire Wrap

172 Series D-Sub Wire Wrap Connector | 15 pin d-sub
Standard Wire Wrap D-Sub Connectors | Machined Contacts check

172-E Series

db9 connector | D-Sub Solder Cup Connector | 172-E Series
Standard Solder Cup D-Sub | Machined Contacts | Economy check

172-E Series

172-e series d-sub vertical mount connector | 9 pin male
Standard PCB Dip Solder D-Sub Connector Straight | Machined | Economy check

173-E Series

173-E Series D-Sub Connector
Standard D-Sub | Right Angle .283" Footprint | Machined | Economy check

174-E Series

db9 connector | Right Angle D-Sub Connector | 174-E Series
Standard D-Sub | Right Angle .370" Footprint | Machined | Economy check

178 Series

178 Series D-Sub Dual Port Connector
Dual-Port D-Sub | .750" Centers check check

179 Series

179 Series D-Sub Dual Port Connector
Dual-Port D-Sub | .900" Centers check check

182 Series

Right Angle D-Sub Connectors | 182 Series
Standard D-Sub | Right Angle .318" footprint | Stamped | Economy check

183 Series

183 Series
Right Angle D-Sub Connectors .590" footprint | Stamped | Economy check

184A Series

184A Series D-Sub Connectors
Low Profile IDC D-Sub Connector check

189 Series

189 Series D-Sub Dual Port Connectors
Dual-Port D-Sub | .625" Centers check check

190/200 Series

200 Series Thumbnail
Standard & HD D-Subs | SMT Right Angle & RA Zero Footprint Through Hole check check check

191 Series Press Fit

191 Series D-Sub Press-Fit Connectors
Standard Density | Press Fit D-Sub Connectors check

191 Series Vertical Low Profile

191 Series D-Sub Vertical Mount Connectors
Standard Density | Vertical Low Profile | D-Sub Connectors check

682 Series

682 SEAL-D® Series IP66 Right Angle
Standard Right Angle D-Sub Connectors - IP66 Rated check

772-E Series

772-E Series D-Sub Solder Cup Connector
Standard Solder Cup D-Sub Connectors - IP67 Rated check check

772-E Series

772-E Series D-Sub Vertical Solder Connector
Standard Vertical Mount D-Sub Connector - IP67 Rated check check

773-E Series

773-E Series D-Sub Right Angle Connector
Standard Right Angle D-Sub Connectors (0.283" Foot Print) - IP67 Rated check check

774-E Series

IP67 Right Angle D-Sub | 0.370" Footprint
Right Angle D-Sub Connectors (0.370" Foot Print) - IP67 Rated check check




DB9 CONNECTOR APPLICATIONS

NorComp DB9 connectors are engineered with machined contacts for heavy-duty industry applications or stamped & formed contacts for applications requiring less mating cycles. Contact us directly if your unique application requires a custom or semi-custom DB9 connector or DB9 cable assembly not currently offered in our standard product offering above.

What is a DB9 Connector?

The DB9 connector, or more accurately the DE9 Connector, is an abbreviated version to reference the 9 pin d-sub connector. The prefix “D” represents the d-shaped connector shell of the d-subminiature connector. The next letter is determined by the 5 shell sizes in accordance with pins (A, B, C, D, & E), which is then followed by the number of sockets or pins (9) housed within the connector shell. Over time the terms DB-9 and DE-9 have become synonymous; and while technically incorrect as the 9 pin shell size is E, are now considered to be interchangeable terms used industry wide.

DB9 Connector Male

The male version of the DB9 connector contains pins or contacts that are either machined or stamped & formed. It is recommended to use machined contacts for more demanding applications that require a more reliable transfer of signal or in systems where a higher number of mating cycles is anticipated. To find out more detailed information, click on a series number above to acces the DB9 connector datasheet & drawing for each type of connector.

Use this link to reference the DE9, or DB9 connector pinout and diagram commonly used for serial ports (RS-232).

Find the NorComp d-sub panel cut-out, or DB9 connector footprint here.
