POWER-D & COMBO-D D-Sub CONNECTORS

The NorComp POWER-D & Combo-D mixed contact d-sub connectors are designed for rugged / robust applications where both power & signal are required from a single connection. Featuring “Solid-Pin” machined contacts, these connectors offer high reliability performance for the most challenging design applications.

Power-D & Combo Mixed Connectors

Power

Series

Description

Solder Cup

Vertical Mount

Right Angle Mount

680M Crimp and Poke

COMBO-D CRIMP & POKE
POWER-D combination D-Sub with Crimp and Poke Contacts

680M Series

7w2 d-sub mixed contact connector | 680M Series
POWER D Mixed Contact Connectors | Machined Contacts check

681M Series

3w3 D-Sub Mixed Contact Connector | 681M Series Power-D M-Series
POWER-D Mixed Contact Connectors - Machined Contacts check

684M Series

3w3 D-Sub Mixed Contact Connector | 684M Series Power-D M-Series
POWER-D Mixed Contact Connectors - Machined Contacts check

Coaxial

Series

Description

Solder Cup

Vertical Mount

Right Angle Mount

682M Series

682 Series Combo-D Connector
Coaxial D-Sub Mixed Contact | 50 ohm check

683M Series

17w2 d-sub mixed contact coaxial connector | 683 Series Combo-D
Coaxial D-Sub Mixed Contact | 50 ohm check

685M Series

9w4 d-sub mixed layout connector | 685 Series Combo-D Connector
Coaxial D-Sub Mixed Contact | 50 ohm check

Power-D SEAL-D®

Series

Description

Solder Cup

Vertical Mount

Right Angle Mount

IP67 Rated

680S Series

3w3 ip67 d-sub mixed contact connector | 680S Series
POWER-D MIxed Contact - Solder Cup - IP67 Rated check check

681S Series

13w3 d-sub mixed contact connector | 681 Series SEAL-D® Power-D
POWER-D Mixed Contact - Vertical PCB Mount - IP67 Rated check check

684S Series

3w3 ip67 d-sub right angle mixed contact connector | 684 Series Power-D
POWER-D Right Angle PCB Mount - IP67 Rated check check

CDF PCB Dip Solder

CDF Vertical Solder
POWER-D MIxed D-sub Flange - Vertical PCB Mount - IP67 Rated check check

CDF Right Angle Solder

CDF Right Angle Solder
POWER-D MIxed D-sub Flange - Right Angle PCB Mount - IP67 Rated check check

CDF Solder Cup

CDF Solder Cup
POWER-D MIxed D-sub Flange - Solder Cup - IP67 Rated check check

SF67 SERIES

IP67 D-Sub Sealing Flanges


Combo D-Sub | Mixed Contact Connector Applications

The NorComp combo d-sub, mixed contact connector product range is ideal for a multitude of both IP rated and non-rated industry applications. This diverse combo d-sub standard product offering includes up to 13 contact configurations (seen below) engineered for both power & coaxial connector environments such as satellite & weather stations, GPS receivers, transceivers and radio technology applications. Contact us directly for any custom or semi-custom combo d-sub connector project not listed in our standard product offering above.
