DB25 Connector | 25 Pin D-Sub Connector

Use the filter below to select the NorComp part number Series containing a DB25 connector, 25 pin d-sub, available in cable and board mount options. NorComp is a leading manufacturer of rugged and robust DB25 connector and cable assembly products engineered to withstand demanding end-use applications.

DB25 Connector Series

Series

Description

Crimp

Solder Cup

Vertical

Right Angle

IP67

170 Series

db9 connector | crimp and poke d-sub connectors | 170 series
Standard Density Crimp & Poke D-Sub Connectors check

171 Series PCB Dip Solder

db25 connector | 171 series dip solder d-sub connector
Standard Straight D-Sub Connectors | Stamped Contacts check

171 Series Solder Cup

db15 connector | 171 series solder cup d-sub connector
Standard Solder Cup D-Sub Connectors | Stamped Contacts check

172 Series High Profile

172 series d-sub high rise connector | 25 pin d-sub
Standard High Profile D-Sub | Machined Contacts check

172 Series PCB Dip Solder

172 series d-sub vertical mount connector | 9 pin d-sub connector
Standard Straight D-Sub Connectors | Machined Contacts check

172 Series Solder Cup

db15 connector | 172 series solder cup d-sub connector
Standard Solder Cup D-Sub | Machined Contacts check

172 Series Wire Wrap

172 Series D-Sub Wire Wrap Connector | 15 pin d-sub
Standard Wire Wrap D-Sub Connectors | Machined Contacts check

172-E Series

db9 connector | D-Sub Solder Cup Connector | 172-E Series
Standard Solder Cup D-Sub | Machined Contacts | Economy check

172-E Series

172-e series d-sub vertical mount connector | 9 pin male
Standard PCB Dip Solder D-Sub Connector Straight | Machined | Economy check

173-E Series

173-E Series D-Sub Connector
Standard D-Sub | Right Angle .283" Footprint | Machined | Economy check

174-E Series

db9 connector | Right Angle D-Sub Connector | 174-E Series
Standard D-Sub | Right Angle .370" Footprint | Machined | Economy check

178 Series

178 Series D-Sub Dual Port Connector
Dual-Port D-Sub | .750" Centers check

179 Series

179 Series D-Sub Dual Port Connector
Dual-Port D-Sub | .900" Centers check

182 Series

Right Angle D-Sub Connectors | 182 Series
Standard D-Sub | Right Angle .318" footprint | Stamped | Economy check

183 Series

183 Series
Right Angle D-Sub Connectors .590" footprint | Stamped | Economy check

189 Series

189 Series D-Sub Dual Port Connectors
Dual-Port D-Sub | .625" Centers check

191 Series Vertical Low Profile

191 Series D-Sub Vertical Mount Connectors
Standard Density | Vertical Low Profile | D-Sub Connectors check

772-E Series

772-E Series D-Sub Solder Cup Connector
Standard Solder Cup D-Sub Connectors - IP67 Rated check check

772-E Series

772-E Series D-Sub Vertical Solder Connector
Standard Vertical Mount D-Sub Connector - IP67 Rated check check

773-E Series

773-E Series D-Sub Right Angle Connector
Standard Right Angle D-Sub Connectors (0.283" Foot Print) - IP67 Rated check check

774-E Series

IP67 Right Angle D-Sub | 0.370" Footprint
Right Angle D-Sub Connectors (0.370" Foot Print) - IP67 Rated check




DB25 Connector Applications

The 25 pin d-sub connector, or DB25, is most commonly known for its use in digital audio and multi-channel applications for recording devices. However, the varying use for both female and male DB25 connector products has expanded to include more rigorous applications where a secure, sometimes waterproof connection and transfer of signal is required amidst high vibration and harsh environments.

DB25 Connector | Standard Density Pin Layout

DB-25 13-12
