IP67 D-Sub Connectors

The highly innovative SEAL-D® IP67 rated waterproof d-sub connectors are sealed internally and maintain the same footprint as our standard d-sub product offering. This IP connector sealing technology has enabled us the flexibility to manufacture any of our existing d-sub product offering in IP67 rated versions.

IP67 D-Sub Connectors

Flanged Connectors

Series

Description

Solder Cup

Vertical Mount

Right Angle Mount

CDF Right Angle Solder

CDF Right Angle Solder
POWER-D MIxed D-sub Flange - Right Angle PCB Mount - IP67 Rated check

CDF Solder Cup

CDF Solder Cup
POWER-D MIxed D-sub Flange - Solder Cup - IP67 Rated check

CDF Vertical Solder

CDF Vertical Solder
POWER-D MIxed D-sub Flange - Vertical PCB Mount - IP67 Rated check

HDF Series

HDF Series
High Density D-Sub Flange - IP67 Rated check check check

SDF Series

SDF-R09-113L011
Standard D-Sub Flange - IP67 Rated check check check

Cable Mount

Series

Description

Solder Cup

High Density

680S Series

3w3 ip67 d-sub mixed contact connector | 680S Series
POWER-D MIxed Contact - Solder Cup - IP67 Rated check

772-E Series

772-E Series D-Sub Solder Cup Connector
Standard Solder Cup D-Sub Connectors - IP67 Rated check

780-M Series Solder Cup

780-M Series High Density D-Sub Solder Cup Connector
High Density D-Sub - IP67 Rated check check

Board Mount

Series

Description

Vertical Mount

Right Angle Mount

High Density

681S Series

13w3 d-sub mixed contact connector | 681 Series SEAL-D® Power-D
POWER-D Mixed Contact - Vertical PCB Mount - IP67 Rated check

684S Series

3w3 ip67 d-sub right angle mixed contact connector | 684 Series Power-D
POWER-D Right Angle PCB Mount - IP67 Rated check

772-E Series

772-E Series D-Sub Vertical Solder Connector
Standard Vertical Mount D-Sub Connector - IP67 Rated check

773-E Series

773-E Series D-Sub Right Angle Connector
Standard Right Angle D-Sub Connectors (0.283" Foot Print) - IP67 Rated check

774-E Series

IP67 Right Angle D-Sub | 0.370" Footprint
Right Angle D-Sub Connectors (0.370" Foot Print) - IP67 Rated check

780-M Series Vertical Mount

780-M Series High Density D-Sub Vertical Solder Connector
High Density D-Sub Connectors - IP67 Rated check check

781-M Series Right Angle

781-M Series High Density D-Sub Right Angle Connector
High Density Right Angle D-Sub (0.350" Footprint) - IP67 Rated check check

Power D | Combo D

Series

Description

Solder Cup

Vertical Mount

Right Angle Mount

680S Series

3w3 ip67 d-sub mixed contact connector | 680S Series
POWER-D MIxed Contact - Solder Cup - IP67 Rated check

681S Series

13w3 d-sub mixed contact connector | 681 Series SEAL-D® Power-D
POWER-D Mixed Contact - Vertical PCB Mount - IP67 Rated check

684S Series

3w3 ip67 d-sub right angle mixed contact connector | 684 Series Power-D
POWER-D Right Angle PCB Mount - IP67 Rated check

Backshell Kit

Series

Description

967 Series

967 Series
180° Top Entry - IP67 Rated D-Sub Backshell

Hardware

Series

Description

967 Series

IP67 Rated Connector Caps

D-Sub Hardware

d-sub hardware | thumbnail
D-Sub // Micro D // D-Sub Backshell

SF67 SERIES

IP67 D-Sub Sealing Flanges


IP67 Connector Technology

The IP67 D-Sub Connector product offering are available in Standard & High Density pin configurations as well as 3 termination types (Cable Mount, Vertical Mount & Right Angle) meeting IP67 connector (IEC 60529) requirements . For more information on the drop in replacement proprietary sealing technology, see the SEAL-D® landing page.

In 2011, NorComp introduced a proprietary sealing technology that transformed our standard sized d-sub connector into an IP67 connector able to fully meet the IEC 60529 IP67 requirement for Ingress Protection (IP). These SEAL-D® IP67 connectors utilize a highly innovative internal sealing technology thus eliminating the need to redesign enclosures and PC boards when implementing IP67 design upgrades. The IP67 requirement met means the connection is guaranteed protection against water streaming from powerful jets as well as up to 30 minutes at 1 meter of submersion.

This IP67 connector technology has been a well received innovation industry wide when compared to its predecessor with a much larger footprint that is sealed externally around the outer shell to meet IP requirements. Moreover, once mated - the NorComp SEAL-D® connectors are rated IP68 connectors capable of protecting against longer periods of submersion under a higher pressure.

IP67 Connector Variations

The NorComp IP67 connector product offering is available in both standard density (9 pin, 15 pin, 25 pin, 37 pin), high density (15 pin, 26 pin, 44 pin, 62 pin), and 22 Combo-D variations in configurations in cable mount, vertical mount & right angle connector options. Rounding out the product offering are IP67 backshells, IP67 sealing caps and sealing flanges.

SEAL-D®

  • Standard: 9 pin, 15 pin, 25 pin
  • High Density: 15 pin, 26 pin, 44 pin
  • Combo-D / High Power in 12 varations

NANOOK

  • Standard: 9 pin, 15 pin, 25 pin, 37 pin
  • High Density: 15 pin, 26 pin, 44 pin, 62 pin
  • Combo-D / High Power in 18 variations

IP67 Connector Applications

The NorComp IP67 connector product offering is engineered for use in a vast amount of heavy-duty, demanding applications across multiple industries. In medical electronics there have been multiple success stories stemming from patient transport devices to hand held computers and scanners that are subject to being washed down continually. More applications include gas and electric water metering systems as well as remote sensors and gauges stationed outdoors that require an IP67 connector solution for a reliable transfer of signal while working under these stressful and harsh environments.
