SEAL-D Header

CONNECTOR SEALING TECHNOLOGY ELIMINATES REDESIGN

NorComp's line of SEAL-D® Waterproof d-sub connectors utilize an innovative sealing technology eliminating the need to redesign enclosures and PC boards when implementing IP67 design upgrades.These connectors are designed for applications that require protection from heavy spray or are exposed to short-term submersion. Connectors are available in vertical and right angle board mount types as well as solder cup for panel mount cable applications. Standard D-Subs are available in 9 pin, 15 pin, and 25 pin positions, and high density D-Subs are available in 15 pin, 26 pin, and 44 pin positions

Example Applications:

  • Hand held computers, scanners, and printers that are used outdoors
  • Remote sensors, gauges, and data loggers that are used outdoors
  • Industrial and Medical equipment that is routinely subject to wash down
  • Transmitters and emergency beacons that are subject to temporary submersion
  • Gas, Electric, and Water metering systems that have embedded Smart Grid electronics
  • Portable electric generation equipment (Gen Sets)
  • Consumer and Commercial boating electronics (Radios, Scanners, Radar, DC Power Ports)

IP67 D-Sub | SEAL-D® Waterproof Connectors

FEATURES & BENEFITS

  • Signal / Low Power in 6 standard size
  • (Standard: 9 pin, 15 pin, 25 pin | High Density: 15 pin, 26 pin,44 pin)
  • Combo-D / High Power in a variety of configurations:
  • (3W3, 5W5, 7W2, 9W4, 11W1, 13W3, 13W6, 17W2, 21W1, 21WA4)
  • Solder Cup, Vertical Mount & Right Angle Board Mount Options
  • High Reliability Screw Machined Contacts
  • 3 amp / 5 amp / 20 amp / 40 amp Power Options
  • -65°C to +105°C Operating Temperature Range

IP66 D-Sub ConnectorS

IP67 D-SUB CONNECTORS

IP67 POWER-D CONNECTORS
