future of circular connectors

VULCON™ circular connectors offer a robust waterproof cable-to-panel/PC board interface for demanding end-use applications. Engineers continue to design-in these industry-standard connectors due to their rugged design and space-savings associated with the more compact connector. Contact-for-contact, these connectors take up less room than rectangular style connectors, enabling the efficient use of mounting connectivity space for multiple design-in applications.

Example Applications:

VULCON™ CIRCULAR CONNECTORS

  • Available in multiple sizes - M5, M8, M12, M16
  • Available in most standard pin counts ranging
  • IP67/IP68 performance in both mated/unmated conditions
  • Solder Cup, Vertical, and Right Angle board mount options
  • Cable mount available loose piece or as pre-made cables
  • Up to 7 amp contact rating / -40°C to +85°C temp. rating
  • Full metal shells for EMI/RFI shielding
  • A, B, D, L, S, T, & X Codes now available through distribution


M5 SERIES

  • M5 connectors available in: 2 pin, 3 pin, 4 pin
  • Non-removable Contacts
  • Meet IP67/IP68 water proof requirements
  • -40°C to +85°C Temperature Range
  • Available as loose piece or as pre-made M5 cables

M8 SERIES

  • M8 connector is available in: 3 pin, 4 pin, 5 pin, 6 pin
  • Non-removable Contacts
  • Meet IP67/IP68 water proof requirements
  • -40°C to +85°C Temperature Range
  • Available as loose piece or as pre-made M8 cables

M12 SERIES

  • M12 connector pin configurations: 3 pin, 4 pin, 5 pin, 6 pin, 8 pin, 12 pin
  • Non-removable Contacts
  • Meet IP67/IP68 water proof requirements
  • -40°C to +85°C Temperature Range
  • Available as loose piece or as a pre-made M12 cables

M12 PIGTAIL SERIES

  • M12 pigtail connector configurations 4 pin, 5 pin, & 8 pin
  • 2 color code option available in both front and rear mount
  • (4 pin & 5 pin only)
  • Packaged in units of 10 per bag
  • Non-removable Contacts
  • Meet IP67/IP68 water proof requirements
  • -40°C to +85°C Temperature Range
  • Available in 2 standard lengths (6" or 12")
  • Custom lengths available - contact factory

M16 SERIES

  • M16 pigtail connector configurations 3 pin, 4 pin, 5 pin, 6 pin, 7 pin, & 8 pin
  • Non-removable Contacts
  • Meet IP67/IP68 water proof requirements
  • -40°C to +85°C Temperature Range
