D-Sub Mixed Contact Connectors | POWER & COAXIAL

The NorComp line of d-sub mixed contact connectors feature “Solid-Pin” machined contacts, offering high reliability performance for the most challenging design applications.

POWER-D / SEAL-D® Expansion

NorComp has expanded it’s SEAL-D® IP67 connector product offering to include POWER-D connectors. These power connectors can carry both signal (5 amp) and power (20 / 40 amp) contacts within the same connector body. Utilizing the SEAL-D® innovative sealing process, these connectors offer the benefit of being direct drop in replacements for standard (unsealed) connectors - which eliminates the need to change PCB and sheet metal designs to upgrade to IP67 performance levels.

Example Applications:

  • Wireless Base Stations
  • Satellite Base Stations
  • Broadband Network Infrastructure
  • RF Power Amplifiers
  • DC/DC Power Supplies
  • DC Motor Controllers
  • Industrial Robotics
  • Servo Control Systems
  • Laboratory Meterology (Test & Measurement)

D-Sub Mixed Contact Connectors

  • Combined footprint allows signal, high current & high voltage in one connector.
  • D-Sub mixed contact connectors in 3 termination types.
  • Screw Machined Contacts for Higher Mating Cycles and more reliable signal transfer.
  • Also available in SEAL-D® Waterproof Option for IP Rated d-sub mixed contact connector solution.

Electrical Mixed Contact Connectors

  • D-Sub Mixed Contact Connectors available in 12 Contact Configurations:
    • 3W3, 3W3K, 5W1, 5W5, 7W2, 8W8, 9W4, 11W1, 13W3, 13W6, 17W2, 21W1, 21WA4
  • Termination Type: Cable Mount, Vertical PCB, Right Angle PCB (Male Only)
  • Current Rating: Power Contact - 20/40amp
  • Current Rating: Signal Contact – 5amp
  • Dielectric Withstanding: 1,000 VAC R.M.S.

Mechanical Mixed Contact Connectors

  • All Contacts are Preloaded (Board & Cable Mount)
  • Contact Insertion Force: 4.5Kg Max.
  • Contact Separator Force: 0.3Kg Min.
  • Process Temperature: 230°C
  • Operating Temperature: -55°C to +155°C


Power-D Series
